Rqlv-g Series
Low Pressure Screw Air Compressor
The low-pressure screw air compressor is a professional and energy-efficient pneumatic power equipment specially designed for industrial scenarios that require stable low-pressure and large-flow compressed air. Different from conventional general-purpose air compressors pursuing high pressure, this series is optimized with a dedicated low-pressure compression host and matching system structure, effectively solving the problems of excessive pressure margin and serious energy waste caused by high-pressure machines used in low-pressure working conditions.
Product Features
1)Durable airend with stable performance.
2)Permanent magnet motor cuts power consumption. IP54 protection class and Class B temperature rise enable reliable operation in harsh environments with heavy dust and high temperatures.
3)Coupling connection design delivers higher energy efficiency.
4)Multi-stage noise reduction structure engineered via acoustic calculation. Special flame-retardant sound-absorbing cotton is lined inside the unit to lower operating noise and create a quieter working environment.
5)The low-pressure screw air compressor is Independent air intake design enhances cooling performance.
6)Low-pressure dedicated cooler paired with low-noise centrifugal fan, featuring large cooling air volume, low noise, fast heat dissipation, and easy cleaning & maintenance.
7)Special cyclone internal-external oil separator tank for low-pressure models improves primary separation efficiency. Matched with dedicated low-pressure oil separator core, it achieves low pressure drop, superior oil removal performance, lower residual oil content in compressed air and longer service life.
8)Openable access doors are installed at the three filter assemblies for easy component replacement and convenient routine maintenance.
9)Specially engineered airend oil supply system stabilizes oil supply pressure, enabling smoother unit operation and extended service life.
10)High-temperature shutdown protection function.
11)Motor overload protection function.
12)Overpressure safety pressure relief system.
13)Optimized shock-absorbing pads reduce vibration and operating noise.
14)Electrical components, oil separation and filter modules vulnerable to high-temperature damage are placed in a cooling chamber, effectively extending the overall service life of the unit.
15)Dual-path pressure monitoring plus single-path temperature control provides comprehensive protection for unit operation.
